Auto Color Mixer

This machine is a device that can automatically mix to two or four ratios such as new material, grinding material and M / B.
Feature
  • Screw feeder can maintain constant weighing accuracy by inverter control method and counter control method.
  • This machine has free fall mixing method and after mixing central mixing method.
  • Input volume can be easily adjusted in touch panel.
zoomin

Composition Type
  • 3 ZONE Color Mixer: New Material × Grinding Material × M / B
  • 4 ZONE Color Mixer: New Material × Grinding Material × M / B + Additive
  • 5 ZONE Color Mixer: New Material 1 × New Material 2 × M / B × Additive 1 × Additive 2
Specification

Model Mixing Capa. (kg/Hr)
ACM - 300 100~300
ACM - 500 300~500
ACM - 1000 500~1000

Specifications of this product may change due to quality improvement.
